Sigatek offers a variety of Broadband Pick-off Tees with low loss, flat response from DC to 40 Ghz.
Pick off tees are resistive couplers that provide non-directional coupling of microwave signals.
A directional coupler offers an isolation of any returned signal to the coupling port whereas the Pick-Off Tee has no isolation.
Applications for these devices include digital oscilloscope pre-scaler triggering, synchronization, and clock/data recovery.

Pick-Off Tees, Pick-Off Couplers, Resistive-Tap Couplers:
Come with SMA or 2.92mm connectors, frequencies DC to 40 Ghz


Part
Number
PDF-Data
Frequency
Range
GHz
Insertion
Loss
dB Max
Pick-Off
Level
dB Max
Flatness
dB Max
Connectors
SMA-2.92mm
VSWR In/Out
db Max
Input
Power
watts Max
Quote
*
Pick-Off Tees SMA and 2.92mm connectors - Pick-Off level -12 dB
Outline-R2F
.
T1210R2F DC-20 1.6 -12±1.0 ±1.0 SMA 1.60:1 1 ORDER
T1211R2F DC-27 1.8 -12±1.0 ±1.0 2.92mm 1.60:1 1 ORDER
T1212R2F DC-40 2.2 -12±1.5 ±1.6 2.92mm 1.80:1 1 ORDER
Pick-Off Tees SMA and 2.92mm connectors - Pick-Off level -15 dB
Outline-R2F
.
T1510R2F DC-20 1.5 -15±1.0 ±1.0 SMA 1.60:1 1 ORDER
T1511R2F DC-27 1.8 -15±1.0 ±1.0 2.92mm 1.60:1 1 ORDER
T1512R2F DC-40 1.9 -15±1.5 ±1.6 2.92mm 1.70:1 1 ORDER
*
- Input Power rating is for load VSWR better than 1.20:1.
- Custom and optimized designs are available.
For Special applications or engineering questions call the sales office at 973-706-8475 or e-mail us at E-MAIL and we shall respond to you promptly.
QUICK DELIVERY FOR OUT OF STOCK PARTS. Request a QUOTE.


Qty. Product Image Item Name Price
0 T1210R2F Pick-Off Tee Coupler 12 dB DC-20 Ghz

T1210R2F Pick-Off Tee Coupler 12 dB DC-20 Ghz

The T1210R2F is a Pick-Off Tee, Pick-Off Coupler, Resistive Coupler, Tap Coupler. It covers DC to 20 Ghz with flat Thru-pass loss and flat Pick-Off path of -12 db. Standard connectors are SMA female,...
$295.00

... more info
 Sold Out

2 T1211R2F Pick-Off Tee Coupler 12 dB DC-27 Ghz

T1211R2F Pick-Off Tee Coupler 12 dB DC-27 Ghz

The T1211R2F is a Pick-Off Tee, Pick-Off Coupler, Resistive Coupler, Tap Coupler. It covers DC to 27 Ghz with flat Thru-pass loss and flat Pick-Off path of -12 db. Standard connectors are 2.92mm...
$375.00

 Buy Now

3 T1212R2F Pick-Off Tee Coupler 12 dB DC-40 Ghz

T1212R2F Pick-Off Tee Coupler 12 dB DC-40 Ghz

The T1212R2F is a Pick-Off Tee, Pick-Off Coupler, Resistive Coupler, Tap Coupler. It covers DC to 40 Ghz with flat Thru-pass loss and flat Pick-Off path of -12 db. Standard connectors are 2.92mm...
$425.00

 Buy Now

0 T1510R2F Pick-Off Tee Coupler 15 dB DC-20 Ghz

T1510R2F Pick-Off Tee Coupler 15 dB DC-20 Ghz

The T1510R2F is a Pick-Off Tee, Pick-Off Coupler, Resistive Coupler, Tap Coupler. It covers DC to 20 Ghz with flat Thru-pass loss and flat Pick-Off path of -15 db. Standard connectors are SMA female,...
$295.00

... more info
 Sold Out

2 T1511R2F Pick-Off Tee Coupler 15 dB DC-27 Ghz

T1511R2F Pick-Off Tee Coupler 15 dB DC-27 Ghz

The T1511R2F is a Pick-Off Tee, Pick-Off Coupler, Resistive Coupler, Tap Coupler. It covers DC to 27 Ghz with flat Thru-pass loss and flat Pick-Off path of -15 db. Standard connectors are 2.92mm...
$375.00

 Buy Now

3 T1512R2F Pick-Off Tee Coupler 15 dB DC-40 Ghz

T1512R2F Pick-Off Tee Coupler 15 dB DC-40 Ghz

The T1512R2F is a Pick-Off Tee, Pick-Off Coupler, Resistive Coupler, Tap Coupler. It covers DC to 40 Ghz with flat Thru-pass loss and flat Pick-Off path of -15 db. Standard connectors are 2.92mm...
$425.00

 Buy Now
